- Note: When installing the Alternator Charger main unit, make sure not to block the power button. After connecting the Alternator Charger to the portable power station（both River and Delta Series） via the XT60 port, you need to press the power button each time you turn on the car to turn it on before initiating charging through the app.
Top up 1kWh (85Ah@12V) in only 2.1 hours
Charge 5× faster while you drive with our EcoFlow 500W Alternator Charger and recharge your power station in only 2.1 hours.With the EcoFlow 500W Alternator Charger, charge 5 times faster than with traditional vehicle auxiliary power outlets simply by using excess energy generated by your vehicle. The charger uses its onboard DC-DC converter to restore your EcoFlow power station's energy while you drive.
Triple the value with a 3-in-1 functional design
The 3-in-1 charger, maintainer, and jump starter saves time, money, and precious in-vehicle space.
With its smart and efficient fast charging capabilities, you'll stay powered no matter how long you're on the road.
- The 500W Alternator Charger comes with an XT60 cable, but does not support reverse charging & battery maintenance functions with the XT60 cable. To enable reverse charging & battery maintenance functions, purchase the XT150 cable and use with an EcoFlow DELTA Series product.
Compatible with all EcoFlow and most third-party power stations
Compatible with an XT60 connection, designed to charge EcoFlow RIVER, DELTA Series, and most third-party power stations. The charger's 500W fast-charging is compatible with most SUV, Pickup, and RV alternators, meeting diverse short-trip car camping power needs.
*When using an XT60 cable, the Alternator Charger switch on the device must be manually turned on and the charging function enabled in the app before charging can begin. Therefore, if planning to use the XT60 cable for output, avoid concealed installation of the Alternator Charger in advance.
More Detailed Specifications for 500W & 800W Alternator Charger
What's in the box
Specs
Model
EF-MS-H02-1
Net Weight
5.7 kg
Dimensions (W × D × H)
242×194×35 mm
Wi-Fi
Frequency: 2412MHz-2472MHz
Maximum output power: 18.22dBm
Bluetooth
Frequency: 2402MHz-2480MHz
Maximum output power: 7.89dBm
Charging Mode
Input: 12V/24V⎓(11V-31V⎓), 45A Max.
Output: 40V-60V⎓, 500W Max.;24V⎓, 360W Max.
Battery Maintenance Mode
Input: 40V-60V⎓, 3A Max.
Output: 13.8V/27.6V⎓, 100W Max.
Reverse Charging Mode
Input: 40V-60V⎓, 13.2A Max.
Output: 13.8V/27.6V⎓, 500W Max.
Fuse's Rated Current
125A
Protection Type
Reverse polarity protection / Overcurrent protection / Short circuit protection / Overvoltage and undervoltage protection (Provided with integral protection against overloads)
