Description
240Ah
quick stats
- Maximum Discharge Rate (5 seconds): 640 amps
- Prismatic Cell Technology: 10,000+ cycles @ 40% DoD
- Warranty: 5 year Australian Warranty
- Safety Certifications: Including IEC:62619
- Lightweight at 24.8kg: Equivalent AGM weighs approx. 140kg
The all-new iTECH240X PRO 240Ah Lithium Battery is the result of years of design and development. Featuring a 100% useable capacity, the iTECH240X PRO is the ultimate power solution for all your energy needs.
With its sleek and compact design, the iTECH240X PRO is a true drop-in replacement for your existing system. No changing of systems, chargers, or equipment is required in most cases. Simply pull out your old AGM or lead-acid batteries and drop in the iTECH240X PRO. It's that easy!
Inside, you’ll find an all-new, patent-pending prismatic cell type paired with a supercharged Battery Management System (BMS). This advanced combination ensures reduced cell degradation and a longer lifespan, even under high current loads, making the iTECH240X PRO fully capable of supporting larger inverter systems, including those with a 3000W capacity.
Built for the tough Australian environment, the iTECH240X PRO is IP67 Waterproof rated, allowing for the battery to be submerged under 1 meter of water for up to 30 minutes - perfect for marine applications or outdoor storage boxes. The iTECH240X PRO utilises the latest prismatic cell design offering more vibration resistance and stability for big bumps with vibration-dampening technology.
Upgrade to the iTECH240X PRO today and experience the ultimate in power and performance.
Package Contents
- 1x iTECH240X PRO 240Ah 12V Lithium Battery
- 1x User Guide
Support
The iTECH240X PRO warranty is 5 years (3 years full replacement 2 years pro-rata).
*Storage deep cycle battery only. It cannot be used as a cranking battery.
If your iTechworld battery enters safe mode, please follow the instructions HERE
| General | |
|---|---|
| Voltage: | 12V |
| Nominal voltage: | 12.8V |
| C20 rating usable Amps: | 240Ah |
| Short circuit protection: | Yes |
| Optimum temperature range: | 5°C ~ 60°C |
| BMS operational temperature range: | -5°C ~ 80°C |
| Safety protection isolator: | 80°C |
| Recommended charge voltage: | 14.4V |
| Maximum charge current: | 150A |
| BMS charge cutoff: | 15V |
| BMS low voltage cutoff: | 10.5V |
| Series connection: | Up to 48V (4 x batteries) |
| Parallel connection: | Unlimited |
| Life cycles @ 80% depth of discharge: | 5,000+ |
| Life cycles @ 40% depth of discharge: | 10,000+ |
| Continuous Discharge Rate: | 200A |
| Maximum Discharge Rate (5 Seconds): | 640A |
| Dimensions (LxWxH): | 485 x 170 x 239mm |
| Weight: | 24.8kg |
| Terminal type: | M8 |
| Case material: | ABS |
